vb-objects for MaxMSP

This is a slowly growing collection of externals made for the programming environment Max/MSP (Cycling’74). Most of them were written for my personal projects – if you run into problems, please let me know.
All objects are compiled for macos (intel/arm64) and come in a simple to install max package found here.

  • vb.allpole~ — an allpole filter
  • vb.aubio~ — onset detection analysis of audio data stored in a buffer~ using aubio
  • vb.blit~ — a bandlimited impulse oscillator
  • vb.brown~ — brownian noise generator
  • vb.cheby~ — a variable order chebyshev filter
  • vb.evolution~ — progressively freezing an input signal
  • vb.fbosc~ — a feedback oscillator
  • vb.fbosc2~ — similar to vb.fbosc~ but with signal inlets
  • vb.FFTWbuf~ — processes non-realtime FFT/iFFT of buffered data
  • vb.fourses~ — a chaotic oscillator after ciat lonbarde
  • vb.freezer~ — freeze audio input into a perfect loop (mac/win)
  • vb.gbuzz~ — impulse generator with spectrum control
  • vb.gcd_lcm — calculate Greates Common Divisor (gcd) and Least Common Multiple (lcm)
  • vb.goertzel~ — goertzel filter implementation, to detect presence of a specific frequency component in a signal
  • vb.jonverb~ — an inexpensive artificial reverb generator after Jon Dattorro
  • vb.linCongru~ — linear congruential pattern generator
  • vb.listchange — same as [change] but for lists
  • vb.listdrunk — same as [drunk] but for lists
  • vb.median~ — a median filter based on SuperCollider’s median UGen by J. McCartney
  • vb.phasor0~ — a phasor that changes its frequency only at the beginning of a new ramp
  • vb.pitch~ — a pitch tracker
  • vb.ramp~ — a ramp generator which can be triggered by a signal
  • vb.rand~ — same as [rand~] but with cubic interpolation
  • vb.simper.svf~ — Andrew Simper’s state variable filter version
  • vb.src~ — high quality variable sample playback using libsamplerate
  • vb.stretch~ — extreme audio stretching
  • vb.thresh~ — same as [thresh~] but with settable gate time

Sources on gitHub.



vb.mi-objects — a collection of mutable instruments eurorack modules for MaxMSP (work in progress!) – for more info about this collection go here
sources on gitHub.



vb.4ms-stuff — a small collection of max objects inspired by eurorack modules by 4ms. At the moment this contains:
vb.rcd~ (a rotating clock divider) and
vb.scm~ (shuffling clock multiplier)



  • max-thirdParty_externals — a collection of legacy externals for MaxMSP developed by various authors. Binaries are compiled for mac (intel/arm) and windows (win64) except where otherwise noted. Sources on github. Currently the package contains:
    • 2up_svf~ by Randy Jones
    • analyzer~ by Tristan Jehan et al. (mac only)
    • bob~ by Miller Puckette
    • ca1s by Jhno (John Eichenseer)
    • cverb~ by ?
    • fluidsynth~ by Peter Hanappe et al. and Norbert Schnell (mac only)
    • freeverb~ by Olaf Matthes
    • gigaverb~ by Olaf Matthes
    • rufus~ by David Zicarelli
    • s2m.wacom by Charles Gondre (macos only)
    • slice~ by Nao Tokui
    • vinylcontrol~ originally written for PD by Niklas Klügel
  • sigmund~  — a 64-bit version of Miller Puckette’s sigmund~ object (mac[intel/arm]/win64).
    Sources on gitHub.
  • fiddle~ — 64 bit version of Miller Puckette’s fiddle~ object for MaxMSP (mac[intel/arm]/win64).
    Sources on gitHub
  • bonk~ — 64 bit version of Miller Puckette’s bonk~ object for MaxMSP (mac[intel/arm]/win64).
    Sources on gitHub.
  • playmp3~ — an object that plays back compressed audio files (mp3, m4a etc.). Note: EXPERIMENTAL STATE!
  • jit.boids — 64 bit version (mac[intel/arm]). A bird flight and animal flock simulator for Jitter. Original by Wesley Smith, a.sier / jasch and Eric Singer. This package contains:
    • jit.boids2d
    • jit.boids3d
    • xray.jit.render
  • csound~v1.1.4(vb+) — an object by Davis Pyon for running csound from inside maxmsp (mac[intel/arm]).
  • vb.metatag — read and write metadata tags for media files using “taglib”. Based on metatag by J. Bernstein



Some UGens for SuperCollider


a modest collection of UGens/plugins for SuperCollider containing:

  • VBFourses, a chaotic oscillator network after ciat lonbarde
  • VBPVoc, a simple PhaseVocoder for time stretching of buffered audio
  • VBJonVerb, a reverb model after Jon Dattorro
  • VBChebyFilt, a steep Chebychev High-/Low-Pass Filter, based on St.Smith’s DSP-Guide
  • Lores, a cheap resonant lowpass filter (based on MaxMSP’s lores~)
  • Slide, smoothing signals with adjustable attack and release times

sources on GitHub
For binaries (macos, linux, windows) go to releases



some SuperCollider UGens/plugins based on euroack modules by mutable instruments, STILL IN DEVELOPEMENT – PLEASE USE WITH CARE!

  • MiBraids, a macro-oscillator based on the Briads module
  • MiClouds, a granular audio processor based on the Clouds module.
  • MiElements, a physical modelling engine based on Elements.
  • MiMu, a µ-law audio compander for softly degrading an input signal, based on code from the Clouds module.
  • MiOmi, ‘ominous’, a dark 2×2-op FM synth voice (from Elements).
  • MiPlaits, a macro-oscillator based on the Plaits module.
  • MiRings, a resonator based on the Rings module.
  • MiRipples, a classic, ‘big-sounding’ analog four-pole filter based on Ripples.
  • MiTides, a quad LFO and unique looping AD envelope generator based on Tides(2).
  • MiVerb, Griesinger reverb unit found in several mi-modules

sources on GitHub
For binaries (macos, linux, windows) go to releases
